Polyester Restraints are constructed similar to an Endless Polyester Roundsling. They are constructed using a continuous loop of core yarns encased in a double wall cover. This cover helps to protect the load bearing yarn from abrasion.
Restraints can use similar color codes as standard roundslings (Lifting Slings) but Polyester Flow Line restraints do offer different capacities than a standard roundsling.
Restraints are not to be used for Overhead Lifting
Features & Benefits
| Part # | Color Code | Max PSI – 2” 1502 | Max PSI – 3” 1502 | Max PSI – 4” 1502 |
|---|---|---|---|---|
| BFR78 | RED | 15,000 | 8,000 | 5,000 |
| BFR160 | BLUE | 20,000 | 15,000 | 10,000 |
| BFR200 | ORANGE | 20,000 | 15,000 | 15,000 |
Manufacturing Tolerance: +/-1” + 2% of specified length and applies to roundslings when new, at the time of final manufacture.
Matched Set Length Tolerance: When multiple legs of a bridle sling are made, or when multiple slings are prescribed to be made within a Matched Set Tolerance, their length variance from their nominal length shall remain within a dimension equal to one-half of their corresponding Standard Length Tolerance Values.
Measurement Method: Roundsling length is measured with the sling laid flat while being manually pulled taut.
Proper Use of Restraints can reduce But Not Eliminate the risk of severe personal injury or death.
